Spline Standard Tip



Click a thumbnail to view a larger image

Spline Standard Tip Features:

  • Fits all spline rotary hammers
  • Patented flute geometry removes dust from the hole quicker for fast drilling and long life
  • Shot-peened, double-tempered finish reduces breakage
  • Copper braze material gives high heat resistance for reduced tip loss
  • All tips made to ANSI specifications
  • Chrome vanadium shaft through-hardened to 50-53HrC
Bookmark and Share

NOTE: Not all products are currently listed on our website. If you don't see the specific product you are looking for, please contact our Customer Service Department for assistance.

Shop OnlineItem #DiameterTwist LengthOverall Length
Shop Online BM3240003/8"4"9"
Shop Online BM3240013/8"8"13"
Shop Online BM3240023/8"11"16"
Shop Online BM3240031/2"6"11"
Shop Online BM3240041/2"8"13"
Shop Online BM3240051/2"11"16"
Shop Online BM3240061/2"18"23"
Shop Online BM3240071/2"22"27"
Shop Online BM3240081/2"31"36"
Shop Online BM3240099/16"8"13"
Shop Online BM3240109/16"18"23"
Shop Online BM3240125/8"11"16"
Shop Online BM3240135/8"18"23"
Shop Online BM3240155/8"31"36"
Shop Online BM3240173/4"6"11"
Shop Online BM3240183/4"8"13"
Shop Online BM3240193/4"11"16"
Shop Online BM3240203/4"18"23"
Shop Online BM3240213/4"22"27"
Shop Online BM3240223/4"31"36"
Shop Online BM3240257/8"11"16"
Shop Online BM3240267/8"18"23"
Shop Online BM3240277/8"31"36"
Shop Online BM3240281"8"13"
Shop Online BM3240291"11"16"
Shop Online BM3240301"18"23"
Shop Online BM3240311"31"36"
Shop Online BM3240331-1/8"11"16"
Shop Online BM3240341-1/8"18"23"
Shop Online BM3240351-1/4"11"16"
Shop Online BM3240361-1/4"18"23"
Shop Online BM3240371-1/4"31"36"
Shop Online BM3240381-3/8"11"16"
Shop Online BM3240391-3/8"18"23"
Shop Online BM3240401-1/2"11"16"
Shop Online BM3240411-1/2"18"23"
Shop Online BM3240431-3/4"18"23"
Shop Online BM3240442"18"23"
